Vibration Welding Machine

What is Plastic Vibration Welding Machine? Linear and track-type vibration welding is a high-precision thermoplastic joining process. Its core principle is to generate frictional heat through precisely controlled linear or track-type reciprocating motion. One component is stationary while the other vibrates at a frequency of 100-240Hz and an amplitude of 1-2mm. This frictional heat melts the plastic at the joint surface, and after cooling and pressure holding, a high-strength molecular-level bond is formed. This technology is suitable for large-area sealing connections such as large automotive parts and complex appliance housings. Its advantages include high joint strength, adaptability to complex workpieces, and support for joining dissimilar materials. Compared to ultrasonic welding, it is more suitable for large parts and glass fiber reinforced plastic processing.





Ultra-high precision and yield: Equipped with AMPA drive technology, achieving ±0.02mm micron-level motion control; 240Hz high-frequency vibration design, welding qualification rate exceeding 99%, supporting optimized welding of complex geometric trajectories.



Superior Cost and Energy Efficiency: Reduces overall cost by 40% compared to traditional processes; CE/UL environmental certification; equipped with an energy recovery system; low power consumption (≤3.5kW/hour), meeting the demands of sustainable production.



Strong Industrial Adaptability: Compatible with all types of thermoplastics such as PP and PE; post-weld substrate strength retention >90%, suitable for automotive and high-end medical component manufacturing; supports Industry 4.0 production line integration; ISO 13953 welding consistency certification.



Intelligent and Convenient Control: Stores over 50 sets of welding parameters and automatically recalls them; RFID mold identification enables rapid mold change within 2 minutes; the human-machine interface features self-diagnostic functions, allowing real-time monitoring of pressure and temperature and providing fault warnings.



Robust and Durable Structure: 20mm thick heavy-duty steel plate body enhances shock resistance; equipped with German-imported bearings with a service life exceeding 50,000 cycles; IP54 protection rating effectively protects against dust and moisture.







High-Efficiency Welding Performance: 20-second rapid welding cycle, employing a low-frequency, high-amplitude vibration design to improve production efficiency.



Superior Bond Strength: For large, complex parts, it can achieve molecular-level bonding with 90-95% substrate strength, resulting in high connection reliability.



Advanced Material Compatibility: Can weld engineering resins with glass fiber/filler content up to 60%, outperforming traditional welding methods.



Clean Assembly Process: No adhesives added; post-weld surface finish reaches Ra≤1.6μm, meeting precision manufacturing requirements.



Comprehensive International Certifications: The equipment has passed multiple international certifications including CE, ISO, and RoHS, meeting production standards worldwide.







Model	WSD-Z150	WSD-Z220	WSD-Z350	WSD-Z500	WSD-Z700	WSD-Z1600	WSD-Z2000
Size	L1650*W960*H1965 mm	L1650*W960*H1965 mm	L2205*W1240*H2226 mm	L2455*W1240*H2226 mm	L2555*W1240*H2226 mm	L3560*W1800*H2640 mm	L3480*W2150*H2765 mm
Max. Mold Weight Capacity	5-15 kgs	5-20 kgs	5-35 kgs	5-50 kgs	5-70 kgs	60-160 kgs	60-200 kgs
Effective Welding Area	50 cm²	60 cm²	150 cm²	280 cm²	450 cm²	450 cm²	450 cm²
Upper Platen Size	L310*W330 mm	L310*W360 mm	L760*W420 mm	L920*W540 mm	L1020*W540 mm	L1600*W540 mm	L2010*W1000 mm
Lower Platen Size	L760*W450 mm	L760*W480 mm	L1200*W520 mm	L1400*W600 mm	L1500*W600 mm	L2400*W700 mm	L2116*W1100 mm
Amplitude	0.1-1.8 mm	0.1-1.8 mm	0.1-1.8 mm	0.1-1.8 mm	0.1-1.8 mm	1-4 mm	1-4 mm
Vibration Frequency	210-260 HZ	210-260 HZ	210-260 HZ	210-260 HZ	210-260 HZ	100-125 HZ	100-125 HZ
Vibration Force	6 KW	8 KW	15 KW	18.5 KW	30 KW	37 KW	37 KW
Rated Power	380 V
Power Supply Requirement	12 KVA	16 KVA	25 KVA	29 KVA	39 KVA	46 KVA	46 KVA
Time & Depth Control	Time, depth mode
Welding Segment	6-Stage Programmable
Stroke Length	300 mm	300 mm	500 mm	500 mm	500 mm	800 mm	800 mm
Net Weight	1580 kg	1780 kg	3750 kg	4350 kg	4750 kg	8760 kg	14000 kg
Warranty	1 Year	1 Year	1 Year	1 Year	1 Year	1 Year	1 Year
MOQ	1 Unit	1 Unit	1 Unit	1 Unit	1 Unit	1 Unit	1 Unit





•Key differences between linear vibration welding and ultrasonic welding: Ultrasonic welding uses a high-frequency, low-amplitude 20-40 KH₂ frequency, suitable for small, precision parts; vibration welding uses a low-frequency, high-amplitude 100-240 Hz frequency (1-2mm), suitable for large parts >250mm.

•Advantages of vibration welding: Efficiently handles large-area joints, stably welds glass fiber reinforced plastics (ultrasonic welding is prone to wear), has high tolerance for dimensional deviations, and provides stronger connections for large parts.

•Advantages of ultrasonic welding: faster cycle time (<1 second, vibration time is 4-10 seconds), lower energy consumption, and more precise control of precision parts; vibration welding has a higher initial investment due to the heavy-duty system.







Vibration welding is best suited for semi-crystalline thermoplastics with excellent heat generation and flowability, such as polyamide (nylon), polypropylene, polyethylene, and polyoxymethylene (POM), all of which can achieve high-quality welds.

l Glass fiber/carbon fiber reinforced polymers are also ideal materials, offering less tool wear and higher stability compared to ultrasonic welding. Engineering plastics such as polycarbonate and ABS can form strong joints, suitable for large components. This process supports welding dissimilar materials, requiring a melting point difference ≤50°C.



Materials with good melt flow properties and medium to high stiffness are more suitable for vibration welding; parts need sufficient stiffness to withstand vibration forces and avoid excessive deformation. Materials with higher heat resistance typically require higher amplitude or longer welding times to ensure complete melting of the joint surfaces.





•Vibration amplitude directly affects the heat generation efficiency of the joint surface: high amplitude (1.5-2mm) accelerates melting and shortens the cycle time, but may damage precision components; low amplitude (0.7-1.2mm) provides gentler heating and reduces the risk of degradation, but requires a longer welding time.



•The optimal amplitude must be matched to the material (semi-crystalline polymers require higher amplitude) and the frequency, pressure, and welding time. Modern equipment can precisely control the amplitude throughout the entire cycle, dynamically adjusting it through programmed curves to balance efficiency and quality.





•Yes, vibration welding is an ideal choice for mass production. Its highly reliable welding stability makes it a core piece of equipment in manufacturing processes with stringent consistency requirements. Modern vibration welding machines can process hundreds of parts per hour, with a standard cycle time of only 4-10 seconds, achieving extremely high production efficiency.



•This process offers good repeatability and minimal part variation, effectively reducing scrap rates in mass production, and can be seamlessly integrated into automated production lines. While the initial investment is higher than some traditional equipment, it offers long-term cost savings through reduced labor, consumables, and maintenance, making it a highly efficient and high-quality choice for large-scale plastic component assembly in industries such as automotive and home appliances.







Vibration welding can optimize weld strength and quality through various joint designs. Common types include:



•Butt joint: A simple edge-to-edge connection suitable for planar parts with sufficient mating area.

•Tongue and groove joint: Improves the self-alignment capability of parts while increasing the welding contact area and enhancing connection strength.

•Shear joint: In addition to molecular bonding, it forms an additional mechanical interlocking structure, resulting in optimal joint strength.

•Energy guide: Employing a triangular or semi-circular ridge structure, it concentrates the initial molten energy in a specific area, improving welding efficiency.

•Stepped joint: Ensures precise alignment of parts while preventing excess molten material (burrs) from appearing on the visible surface.



The optimal joint design needs to be determined based on the part geometry, material, and structural requirements. Most designs include a 1-2° draft angle to balance demolding and welding alignment. Shear joints offer the best strength due to their mechanical interlocking and large bonding area.





•Material Matching: The appropriate frequency and amplitude of the equipment must be selected based on the melting point and mechanical properties of the thermoplastic.

•Part Compatibility: The equipment fixtures and worktable dimensions must meet the part size requirements. For complex parts, prioritize models with programmable welding curves.

•Production Configuration: Mass production requires an automated system; small-batch production can utilize flexible, manually loaded equipment.

•Control System: Prioritize equipment with high precision, good repeatability, and data acquisition capabilities for easy process verification and troubleshooting.

•After-Sales Support: Consider the manufacturer's brand reputation, after-sales support, and training services to ensure long-term stable operation of the equipment.





The following safety precautions must be taken when operating vibration welding equipment: The equipment should be equipped with an interlocked safety door or light curtain, which should immediately stop the machine upon triggering; operators must wear anti-splash safety glasses, heat-resistant gloves, and noise-reducing (≤85 decibels) protective gear; an emergency stop button and warning signs should be prominently displayed on the equipment; modern equipment should be equipped with a two-hand control device to ensure operational safety.



Furthermore, regular safety training is essential, covering correct equipment operation methods, hazard identification, and emergency response procedures; during equipment maintenance, the lockout/tagout (LOTO) procedure must be strictly followed to prevent accidental start-up; sufficient spacing should be maintained in multi-equipment production workshops to ensure safe personnel movement and reduce noise exposure.



Vibration Welding Application Cases: widely compatible with various thermoplastics, including amorphous resins (ABS/PC, PVC, PMMA, PES) and semi-crystalline resins (HDPE, PA, PP, TPO), etc.



Automotive Interior Parts : Vibration welding machines are core equipment for connecting automotive interior parts, capable of precision welding door panels, dashboards, and other components. The joints conform to IATF 16949 standards, with invisible welds and stable performance in extreme temperatures ranging from -40°C to +85°C.



Automotive Exterior Parts :This technology allows for precise connection of automotive exterior components, including safety systems, spoilers, and mudguards. Welded parts conform to ISO 13258 standards, with surface finish meeting automotive OEM requirements.



Automotive Functional Parts :Vibration welding reliably connects critical automotive functional components, covering core components of four major systems: fuel, thermal management, powertrain, and filtration. The process complies with automotive industry standards, ensuring structural integrity and long-term reliability.



Home Appliances: In the home appliance manufacturing industry, this technology enables robust connections of functional components such as washing machine drums, refrigerator liners, control panels, multi-layer doors, buttons, and brackets. Welded joint strength can reach over 90% of the base material strength, providing excellent airtight sealing. The surface treatment reaches Grade A, fully complying with home appliance manufacturing standards.



For certification documentation, transparent pricing, and customized production solutions, please feel free to contact us.



Each automated welding system offers a rapid return on investment through the following advantages: ✓ Precision engineering design (±0.1mm repeatability, ensuring consistent weld quality); ✓ Customized integration solutions (tailor-made tooling and material parameters); ✓ Plug-and-play production capabilities (80% faster cycle time compared to manual welding). Currently, over 1200 manufacturing companies worldwide have chosen our vibration welding solutions for the assembly of core plastic components.
